XB2-ES542 Pushbutton Switch
Product Description: XB2-ES542 Pushbutton Switch
Model: LAY5-EC542
Colour: red
Rated insulation voltage: 600VAC 50/60Hz
Rated operating voltage: 400V
Contacts voltage: 250V
Conventional thermal current: 10A
Contacts load capacity: 10A
Contacts configuration: SPST - NC
Insulation resistance: >50MOhm
Contacts resistance: <25mOhm
Electrical life: 5 000 000 cycles
Mechanical life: 1 000 000 cycles
Operating temperature: -25°C~+55°C
Sealing/Protection Grade: IP65
Air humidity: <85%
Altitude: 2000m
Pollution degree: 3
Backlight colour/illumination: none
Conductor mounting: screw terminals
Mounting: panel mounting
Body material: PVC
Contacts material: silver alloy
Mounting hole diameter: M22
Diameter: ф 40mm
Cap height: 36.5mm
